Garage Insulation Kit

Total: £161.76 Ex. VAT Total: £194.11 Inc. VAT

Floor Kit Size

Roof and Wall Kit

Quantity:

Garage Insulation Kit

Total: £161.76 Ex. VAT Total: £194.11 Inc. VAT

Floor Kit Size

Roof and Wall Kit

Quantity:

Key Features

High-Performing Vapour Control Layer
Made from 83% Recycled Material
Save up to 10% in Space and 30% in Cost
Flexible. Thin and Easy to Install
Rolls of insulation are 1.5m x 10m
15m2 of coverage per roll
Compresses down to 5mm
Both Wall insulation and Floor insulation
All fitting items are included within the kit
High-performing Vapour Control Layer
UK Manufactured - Ecohome Insulation
Free next working day delivery on orders before 2 pm

Featured Video

Description

The Ultimate Garage Insulation Kit

The Multifoil Insulation experts have designed a great value Garage Insulation Kit, that can be installed easily!

When installed the Garage Insulation Kit offers you a solution to combat the common issues we all face in Garages, such as dampness and being excessively cold / hot.

Specifically, the Insulation Kit has been designed with High Performing Multifoils, to keep your garage at an ambient temperature all year round. It does so by reflecting away excess heat in the summer, but also retaining radiant heat in the winter.

The Multifoil Insulation also has a built in Vapour Control Layer, when taped and sealed with the ThermaSeal Foil Joining Tape (Which is also included within the Insulation Kit).

What does the EcoPro Garage Insulation Kit include?

EcoQuilt Expert, to Insulate the Roof, Walls, and Door – This Multifoil has a built-in vapour control layer, multiple layers of wadding and foam. The outer layers are highly reflective which helps to maintain a comfortable temperature inside.
EcoTec Floor-Foam, to Insulate the Floor.
Thermaseal Double Sided Tape 50mm x 33m (If purchasing the Floor Option).
Thermaseal Foil Joining Tape – to seal all edges and joints.
Staple Gun Kit – Including a Heavy Duty Staple Gun and 5,000 14mm Staples.
Cutting Knife.

EcoQuilt Expert, is equivalent to around 50mm of Rigid PIR such as Kingspan / Celotex – yet is just 15mm in thickness. This is a massive advantage, as we all know how important this space is. Despite it being relatively thin comparably – it has got 6 layers!

You do also have the option to insulate the Floor.

If the ‘Floor’ option is selected you will also receive:

EcoTec Floor Foam – To Insulate the Floor (1.2 x 25m Rolls) Thermaseal Foil Joining Tape – To seal all the edges and joints Thermaseal Double Sided Tape The material used to Insulate the Floor is just 4mm in thickness – it is a highly reflective dense foam, that prevents cold bridging.

If you’re interested in just insulating your garage door check out our EcoPro Garage Door Insulation kit.

You can use the Calculator, on this Product Page to calculate how much insulation you will actually need.

If you require any more information, or if you would prefer to Contact Us feel free!

How-To Videos

How To Convert your Garage Into a Workshop

How-To Guides

How to Insulate your Garage Door

1. Clean the Garage Door

The back of the garage door, that faces internally should be completely clean. It should be free from grease, dirt and debris. You should first use a brush to wipe away any of the loose dirt. Follow with a damp cloth and clean until there is no dirt. Allow the door to dry prior to installation. NOTE: This step is critical, as a clean surface will enable the multifoil to hold securely in place.

2. Measure the Garage Door

Measure the Garage Door, both width and height and note these dimensions. This will ensure you cut the correct amount of material.

3. Roll the Insulation out and Cut

Use the Multifoil Insulation Scissors and cut the insulation to size so that the first run covers the entire width.

4. Install Double Sided Tape

Install the double sided tape, at regular intervals distributing evenly on the door edge or bracing. Press down firmly on the tape to ensure you get a good secure bond between the multifoil insulation and the garage door.

5. Remove the Backing Paper and Secure

Start at the bottom right hand side and remove the backing paper, just before insulating. Ensure the insulation is pulled tort and then put pressure where the insulation meet the double sided adhesive tape

6. Repeat

Repeat steps until you have full coverage, overlap each layer slightly to ensure continuous to get the best outcome. You may need to cut the multifoil insulation to ensure you do not have an overhang and that it is the perfect fit.

7. Thermaseal Foil Joining Tape the Joints

To finish, apply the Thermaseal Foil Joining Tape to the joins on the insulation (between each strip) We always advise using foil joining tape all around the edges too - at the top of the garage door tape along the insulation - but also wrap it over the edge of the garage door - for both support and to ensure an effective seal.

Specification

Length	10m
Width	1.5m
Thickness	15mm (5mm Compressed)
Roll Coverage	15m²
Layers	6
Weight	5.5KG
Core R-value	0.93m²K/W
Roof R-value	1.83m²K/W
Wall R-value	2.27m²K/W
Floor R-value	up to 5.56m²K/W
Foil Emissivity	0.05
Water Vapour Resistance	600MNs/g

Question and Answer

Do I need to insulate the floor?

Performance wise it is recommended to insulate the floor using our EcoTec FloorFoam which is also available in this kit. If you’re using your garage for cars, or heavy machinery and it gets a lot of wear and tear you should use some plywood over the top to prevent damage to the insulation. There is also the option to not insulate the floors if you don’t feel like it’s needed.

Do you need to board over the floor and walls?

This is something that’s completely up to you if you’re wanting to insulate your garage so it can be used as an extra room, and you don’t want to see the silver insulation you can. Boarding over the insulation can help to protect it from any damage. For the floors, dense rubber matting is a great choice because it’s made for heavy machinery and can take a lot of weight. However, you do not need to board over the insulation.

Do you need to use battens, or can you install the insulation directly to the wall?

The insulation works by expanding into the open space behind the battens and trapping warm air inside. You will still gain benefit from applying it straight to the wall, but the performance won’t be as good as installing it with battens with a 25mm gap. You would expect to lose 20% performance from removing an air cavity.

Do I need to tape and seal the insulation?

Yes, we recommend taping and sealing over all joints and overlaps on the roof and walls. This will help the products to act as a high-performing vapor control layer. However, if you’re insulating the floor, you still need to tape and seal the perimeter but leave the overlaps un-taped, this will ensure any moisture will escape below.

Is it suitable for all year-round use?

Insulating the roof and wall would be suitable for all year-round use. Having a heat source in the garage would allow for comfortable use in the winter.

Can I cut the insulation?

Our products can easily be cut with a cutting knife or a large pair of scissors. EcoQuilt Expert is a multi-layered insulation, however it has kimbles which keeps all layers together when cutting.
